1. Advancing the Art of Video Endoscopy with High Definition Technology
2. Enhanced image quality and efficient setup.
3. The separate design video endoscopy center is equipped with cutting edge COMS technology, superior algorithm,built-in and easy-of-use functions to present exceptionally high-resolution endoscopic images of clear clarity in every detail.
4. This system helps physicians conduct system setup and procedures efficiently.
High definition images
The endoscopy processor in combination with high resolution scopes delivers the sophisticated endoscopic images via improved image processing technology, enhanced color reproduction, minimized image noise and reduced halation.
IPS display screen
The IPS display screen with 60fp/s capacity presents the optimal color reproduction for both still and dynamic endoscopic images
By adopting the cutting-edge 1280*720p CMOS sensor, the digital high-resolution endoscopes realize enhanced and more clear observation. With the progressive scanning method, exceptionally high definition still endoscopic images of clear clarity in every detail are produced. Used in combination with 26inch IPS display monitor of 60FPS capacity, smooth and clear dynamic is presented as well.
The new generation endoscope control section is of small size, lighter weight and equipped with remote control button and advanced ergonomics which allows the medical staff to conduct optimal insertion and sophisticated procedures with ease and enables enhanced user-friendly operation experiences.
Cleanliness and safety focused on full defense against disinfection.
Easily soiled Air/Water valve, suction valve and instrument portal valve are removeable which facilitates the cleaning and disinfection not only of themselves but also of the inner channels. A smoother, flatter and waterproof endoscope body assures all areas receive optimal contact with cleaning and high-performance disinfecting solutions which enhances the efficiency and effectiveness of CDS procedures.
|Field of view||145°||145°|
|Direction of view||Forward viewing||Forward viewing|
|Depth of view||3-100mm||3-100mm|
|Distal end outer diameter||9.2mm||12.8mm|
|Distal end enlarged||diameter 2.8mm||diameter 3.7mm|
|Insertion tube outer diameter||9.2mm||12.8mm|
|Channel inner diameter||2.8mm||3.7mm|
|Angulation range||UP/DOWN210°/90°; LIGHT/RIGHT100°/100°||UP/DOWN180°/180°; LIGHT/RIGHT160°/160°|
