Opg dental x-ray

T/T in advance, Western Union, L/C, MoneyGram, Cash
Lead time:
3-15 working days

    Opg dental x-ray

    Digital Panoramic Parameters
    Power Supply: 220V,50/60Hz,10A (can be adjusted as customer’s require)
    Mains Resistance: <1.5ohm at 220 V
    X-ray generator:High frequency dc at 20 kHz
    Anodic Voltage:60-86 kV, Constant Potential   Anodic Current:4-10 mA,Direct Current
    Focus size:0.5*0.5mm                     Inherent Filtration:2.5 mm Al
    Column Height:230cm                     Displacement :90 cm,from 90 to 180 cm
    Vertical Movement: Manual Adjustment
    Patient Positioning: Manual Carriage Adjustment
    Centering Light Lateral
    Centering Chin rest
    Reference with bite wing

    Opg dental x-ray

    Imaging Parameters of Digital Sensor ipan

    Color Depth

    12bits (4096gray scale)

    Pixel Size




    Scan Time

    10–20sec(depending on host machine)

    Cephalometric Function Parameters
    (Film available)
    Anodic Current: 10 MA
    The Product of Anodic Current and Time is from 2mAs to 35mAs, divided into 12 block.
    Size of Cassette: 18cm * 24c

    Opg dental x-ray

    Package Information
    Items              Dimensions           G.W.
    main part:     114×83×61cm        154kg
    Side arm:      232×30×34cm        68kg

    Total:                                        222kg
