Medical Ultrasound Video Thermal Printer For Ultrasound Machine
Medical Ultrasound Video Thermal Printer For Ultrasound Machine
Technical parameters
Print Method | Thermal printing on thermal sensitive paper | ||
Dot Denalty | 1280 dot/100 mm(325dol) | ||
Resolution(dot) | print Size | NTSC | PAL |
Normal | 1280*500 | 280*600 | |
Side(landscape) | 1280*1250 | 280*1275 | |
Gray scale | 256 levels |
|
|
| Print Size | NTSC | 280*1275 |
Print Size | Print Size | 100*75mm | 100*75mm |
3.9*2.9mm | 3.9*2.9mm | ||
Side(Landscape) | 130*98mm | 130*98mm | |
5.1 *3.8inches | 5.1*3.8inches | ||
Print speed | Print Size | NTSC | PAL |
Print Size | 3.3sec | 3.9sec | |
Print Size | 8.4sec | 8.4sec | |
Input Signal | Standard composite video(NTSC and PAL) | ||
Dimensions(W*H*D) | 154*89.5*258mm(8*3.5*10inches) | ||
weight | Approx 2.8KG(6.16Ibs) | ||
Dual Power Supply | AC 100-240V, 50/60hz | ||
Power Consumption | 1.5 to 0.8 amp | ||
Regulatory Approvals | UL2601-1,CAN/CSA C22.2 No.601.1(C-UL),FCC-Class A TUV-GS,TUV-GM,CE Mark, (EMC, 89/336/EEC), CCC | ||
Accessories | Instruction book, thermal paper(K91HG),cleaning paper BNC/BNC cable, wired remode. | ||
