Laboratory Digital Overhead Stirrer Agitator

Payment:
T/T in advance, Western Union, L/C, MoneyGram, Cash
Lead time:
3-15 working days
MOQ:
1 SET
Model:
MCL-D12

    Laboratory Digital Overhead Stirrer Agitator

    Model:MCL-D12

    Laboratory Digital Overhead Stirrer Agitator 7

    Laboratory Digital Overhead Stirrer Agitator 8

    Features:
    *High reliability and outstanding performance.
    *LCD display for precise monitoring of set and actual speeds, a wide range of speed from 50 to 2200rpm with control accuracy of  ±3rpm.
    *Brushless DC motor for long life, maintenance free and explosion proof Torque trend display for real-time information on viscosity ,changes.
    *Safety circuits allow for safe stop function in anti-stall or overload conditions.
    *Smooth operation prevents accidental spillage and splashing.
    *Provides constant speed even with changes in viscosities of the samples.
    *Remote function provide PC control and data transmission.
    *Availability of auto-restart function in case of power loss for overnight operations.
    Specification:



    Max. stirring quantity[H2O]

    20L

    Power

    70W

    Motor type

    brushless DC motor

    Motor input power

    60W

    Motor output power

    50W

    Speed range

    50-2200rpm

    Speed display accuracy

    ±3rpm

    Speed display

    LCD

    Torque display

    LCD

    Voltage

    100-220V, 50/60 Hz

    Overload protection display

    LED lights

    Max. torque

    40Ncm

    Viscosity max.

    10000mPas

    Chuck range diameter

    0.5-10mm

    Dimension[W×D×H]

    83x220x186mm

    Weight

    2.8kg

    Protection class

    IP21

    Permissible ambient temperature and humidity

    5-40°C,    80%RH

    Data connector

    RS232
