ECG Machine
ECG high quality cheap portable ECG machine 12 channel CE 1
ECG high quality cheap portable ECG machine 12 channel CE 1

ECG high quality cheap portable ECG machine 12 channel CE

    ECG high quality cheap portable ECG machine 12 channel CE

    ECG high quality cheap portable ECG machine 12 channel CE 2

    Input circuit Isolated input circuit
    Printout Format 6,6+1,6+2,12+2,12
    Operation mode Auto: Automatic lead change: automatic measurement and interpretation  MAN: Manual lead change
    Frequency response 0.05Hz ~ 100Hz
    CMRR >60dB, >100dB(AC filter in use)
    Time constant ≥ 3.2s
    Patient leak current <10µA
    Calibration voltage 1mV±5%
    Sensitivity
    2.5, 5, 10, 20 mm/mV ±3%
    Noise leve <15µVp-p
    Input impedance >50MΩ
    Recording mode thermal printing system
    Thermal printer  8 dot/mm(Vertical)  32 dot/mm(Horizontal, 25mm/s)
    Measurement parameters Ventricle heart rate, P-R interval, QRS Duration,  QT/QTC interval, P/QRS/T axis ,  RV5, SV1, RV5/SV1 amplitude
    Filter AC filter,EMC filter,DFT filter
    Paper size 210mm×20m roll type paper,or 210mmx140mmx20m Z-folding paper.
    Skin voltageTolerance  ±500mV
    Papar speed  6.25, 12.5, 25, 50mm/s
    ECG high quality cheap portable ECG machine 12 channel CE 3ECG high quality cheap portable ECG machine 12 channel CE 4ECG high quality cheap portable ECG machine 12 channel CE 5ECG high quality cheap portable ECG machine 12 channel CE 6ECG high quality cheap portable ECG machine 12 channel CE 7
