Digital Portable X-ray System
Digital Portable X-ray System
Main Component | Tech Spe. | |
Generator | Voltage | AC220V ± 22V |
Power | 5kW | |
kV Range | 40～110kV | |
mA Range | 20～100mA | |
mAs Range | 0.2-200mAs | |
Working Frequency | ≥40kHz | |
Exposure time | 0.01S～4S | |
Anode heat storage | 56KHU | |
X-ray tube | Focus | 0.6/1.8mm |
Inherent filtration | 1mm Al/75Kv | |
Collimator | Light source | LED |
Touch Screen | Dimension | 10.4inch |
Scintillator | CsI | |
Wire Flat Panel Detector | Pixel Pitch | 139 |
17*17inch | Limit resolution | 3.6 |
Pixels | 3072*3072 | |
Laptop | CPU | Intel Core i5 |
Memory capacity | 4GB | |
Physical Spe. |
| |
Main Unit | Weight | 19 kg |
Dimension | 290×265×230 mm | |
Features
-Profession Acquisition Software
Support different brand of X-ray generators
Support Multi- languages
Support RIS/PACS/DICOM Printer Connection
Support professional tools
-Professional and efficient DR workstation
Patient management
Image capture
Image post-processing
Print and storage
-It can be widely use for human limbs checking, diagnosing, especially used in hospital room, ambulance,
disaster relief, emergency medical treatment, sports events, charity organizations, diagnosis etc.
-Deft and concise
6 periods of digital LED display
Failure self-protection, self-diagnosis
High precision control of tube voltage, tube current
48 kinds of presupposed anatomy memory pattern choice
Accuracy control method of simulation and double digital loops
X-ray tube complete surrender by lead for protect X-ray leaking
