ECG Machine
12-channel ECG-1212 electrocardiograph portable ECG machine 1
12-channel ECG-1212 electrocardiograph portable ECG machine 1

12-channel ECG-1212 electrocardiograph portable ECG machine

    12-channel ECG-1212 electrocardiograph portable ECG machine

    12-channel ECG-1212 electrocardiograph portable ECG machine 2

    Real manufacturer 12-channel ECG-1212 electrocardiograph portable ECG machine



    Leads 9/12 leads simultaneous acquisition
    Sampling Rate   16000Hz/channel/secong
    A/D Resolution  24bits
    HR Range  30~300bpm
    Time constant ≥ 3.2s
    Polarizing Voltage  ±600mV
    Input impedance >50MΩ
    Frequency Response 0.01~300Hz
    Noise leve ≤12.5µVp-p
    DFT Filter 0.01/0.05/0.32/0.67Hz
    EMG Filter /Low Pass 25/35/45/75/100/150/270/300Hz
    Pacemaker Detection  Amplitude:±750uV ~±700mv,Width 50 us ~2.0 ms                                                       Sampling Frequency :16000Hz
    LCD Display 10.1inch TFT color LCD (1024*600) with toch screen)
    Power Supply  AC input with external power adaptor of 100~240V,50/60Hz                                              rechargeable Lithium battery (4400mAH) supporting 400 exams.
    Recording Speed   5/6.25, 10/12.5/25/50mm/s
    Recording Paper  Z-fold 210×295mm×100sheets Roller type 210mm×20/30mm
    12-channel ECG-1212 electrocardiograph portable ECG machine 3

    12-channel ECG-1212 electrocardiograph portable ECG machine 4

    12-channel ECG-1212 electrocardiograph portable ECG machine 5

    12-channel ECG-1212 electrocardiograph portable ECG machine 6

    12-channel ECG-1212 electrocardiograph portable ECG machine 7

    12-channel ECG-1212 electrocardiograph portable ECG machine 8
